Drone On-board 4G-LTE Private Networking System

Model: Patron-X10

It is a highly integrated airborne wireless emergency communication system, which integrates baseband processing unit(BBU), Remote Radio Unit(RRU), Evolved Packet Core(EPC) multimedia dispatch server and a tethered drone for qulickly building a LTE wireless network covering a 20km large area in emergency scenarios.

Patron-X10 provides rich services LTE-based such as professional trunking voice, multimedia dispatch, real-time video transferring, GIS location, audio/video full duplex conversation to help first responders make accurate decision.
Availability:
  • Patron-X10

Product Description

Product Highlights


The Tethered Drone SystemPortable LTE Base Station

➢Support 7*24h hovering in the air to meet the long working hours requirement  in emergency scenarios.

➢The tethered drone system includes an Unmanned Aerial Vehicle, Ground Power Supply

Equipment, Tether Management System, Tether Cable and Onboard wireless emergency communication system.

➢Hovering Altitude: 100meters

➢Flight Time: >8hours

➢Anti-wind capability:Level-6



Airborne wireless emergency communication system

➢Highly integrates baseband processing unit(BBU), Remote Radio Unit(RRU), Evolved Packet Core(EPC) multimedia dispatch server, tethered drone and antennas.

➢Provides LTE-based services, professional trunking voice, multimedia dispatch, real-time video transferring, GIS location, audio/video full duplex conversation etc,.


On-board Emergency Communication System

➢It is a truly airborne integrated communication system that can quickly complete the coverage of on-site wireless emergency communication networks.

➢Frequency Band: 400MH/600MHz/1.4GHz/1.8GHz (Bands from 400MHz to 6GHz for option)


Light & Easy to Operate

➢Small size (<10L), light weight (≤5.5kg)


Large Area Covering

➢Transmit Power: ≥20watts

➢Wide Coverage: 20km(suburban environment)


Specifications


Tethered Drone System Emergency Communication System
Wheelbase 1200mm Technology TD-LTE
Unfold Dimension 1764mm Frequency Band

400Mhz: 400Mhz-430Mhz

600Mhz: 566Mhz-626Mhz, 606Mhz-678Mhz

1.4Ghz: 1447Mhz-1467Mhz

1.8Ghz: 1785Mhz-1805Mhz

(Bands from 400MHz to 6GHz available)

Maximum Airborne Load 10kg Bandwidth 20MHz/10MHz/15MHz/5Mhz
Ground Power Supply 7000W Max RF Power

10Watts(400Mhz/600MHz)

15Watts(1.4Ghz/1.8GHz)

Tether Cable 120meters Throughput

DL: ≤80mbps

UL: ≤30mbps

Tether Management System Automatically collect and release the tether cable Users 200
Maximum Lift Height 100meters Power Consumption 150watts
Hover Accuracy Centimeter Level Working Temperature -20°C ~60°C
Wind Resistance Level-6 Weight 5.5kg
Flight Time

7*24hours

(Ground Power Supply)

Dimension 330*260*110mm
