8-12km TCP/UDP COFDM UAV Video And Data Links

Model: FIP-2410

FIP-2410 mini transceiver is a new designed TDD-COFDM wireless communication equipment based on military standard. It supports 2.3-2.5Ghz, transmitting HD IP Video and Bi-directional for 8-12km air to ground. With dual 10/100Mbps Ethernet interface and serial port, it provides HD video and bi-directional data transmission in real time.

  • FIP-2410

Product Description

COFDM UAV Video And Data Links


➢ Double100Mbps Ethernet port support UDP/TCP

➢ One Serial port support Telemetry/MAVLINK/TT

➢ Serial port supports APM, Pixhawk 2.1, Pixhack V3, Pixhawk 2 & Pixhawk4

➢ AES encryption video transmission

➢ Excellent performance in movement condition support max moving speed 400km/h

➢ Working frequency 2.3Ghz/2.4Ghz/2.5Ghz for option

➢ Transmit Rate 3/6Mbps

➢ Bandwidth 4/8Mhz



8-12km UAV Video Links


➢ CNC technology double aluminum alloy housings featured, good impact resistance and heat dissipation

➢ Conductive anodizing craft improves the integrity of RF signals

➢ Working Temperature: -40℃—+85℃


FIP-2410 Dimension






➢ Overall Dimension: 67.5×47.5x14.8mm

➢ Weight: 68g


Specifications

Frequency 2.3Ghz(2304Mhz-2390Mhz): 2T2R
2.4GHz(2402Mhz-2482MHz): 1T1R (2T2R on request)
2.5Ghz(2500Mhz-2570Mhz): 2T2R
RF Transmitting Power 30dBm(air to ground 8-12km)
Antenna Gain

TX:Omni antenna  19.6cm  3.5dbi

RX:Omni antenna  24.9cm    7dbi

Frequency Bandwidth

4Mhz(Default)

8MHz(For your option)

Buad rate Software adjustment
Encryption AES 128
Transmission Mode point to point
Error Detection LDPC FEC
Start-up time 25s
Two-way function Support video and duplex data simultaneously
Data TTL (±3.3V)
Transmission Rate

3Mbps@4Mhz

6Mbps@8Mhz

Serial Baud Rate 115200bps
Receive Sensitivity

-100dbm@4Mhz

-95dbm@8Mhz

Power DC7-18V(DC12V Suggested)
Power Consumption TX: 6Watts
RX: 5Watts
Temperature Operating temperature: -40 ~ +85°C
Storage temperature: -55 ~ +85°C
Interface Power input interface × 1
Antenna interface × 1 (2.3Ghz and 2.5Ghz Antenna interface x 2)
Ethernet Interface × 2
Serial Interface*1
Indicator Power indicator(8)
Connection Status Indicator(4, 5, 6, 7)

Signal Strength Indicator(1, 2, 3)

Metal Case Design CNC technology
Double aluminum alloy shell
Conductive anodizing craft
Size 67.5×47.5x14.8mm
Net Weight Tx: 68g

Rx: 68g
