Hand-held HDMI MIMO MESH Radios

Model: FD-6700M

FD-6700M is a 2×2 MIMO MESH radio, delivering full HD hdmi camera video and full duplex data in a miniature package. It is ideal for use in portable and embedded applications where size, weight, power or cost are key.

FD-6700M is based on TD-LTE technology standard with the best sensitivity in complex RF environment to provide the most Mobile Ad Hoc Networking (MANET) for users. It is built to create powerful, secure networks anywhere, the FD-6700M unites all your critical data sources in real time – giving you and your team the confidence to make difficult decisions in the heat of the moment.
Availability:
  • FD-6700M
  • IFLY

Product Description

Features


➢Rugged "brick" design (powered by embedded battery)

➢Rugged handheld type for fast moving and portable

➢Software configurable RF bandwidth between 5MHz/10Mhz and 20MHz

➢10hours continuous working battery built in

➢Self-forming, self-healing mesh architecture

➢Ideal for use for wide area coverage & multi-hop, mobile applications such as robotics

➢HD video encoder - data capacity of 30Mbps of IP data

➢Built in composite video encoder

➢Built in GPS receiver(option)

➢Built in encryption ZUC/SNOW3G/AES(128/256)OptionalLayer-2



Maintain maximum mobility

As a handheld MESH Smart Radio, the FD-6700M significantly decreases the amount of gear uers have to carry. The battery built in supports 10hours continuous working. Having one fully capable MESH Radio platform frees up valuable space and weight so you can focus more on the task at hand. Fewer cables, fewer batteries, fewer worries.



2x2 MIMO

Users take the FD-6700M mesh radio through cities, tunnels, and ships or other complex RF environments, where its 2x2 MIMO technology uses reflections from obstructions to move your data even faster. The self-forming/self-healing MANET technology routes your data around obstacles, maximizing your network performance and mobility. The more radios you employ, the more connected you become.

COFDM MESH


GENERAL
MECHANICAL
Technology MESH Based on TD-LTE Technology standard Protection IP66
Encryption ZUC/SNOW3G/AES(128/256) OptionalLayer-2 Dimension

180*90*60mm

Data Rate 30Mbps Weight 1.3kg
Node 32 POWER
Sensitivity -103dBm/10Mhz Voltage DC9-12V
Range 1km-3km(NLOS) Comsumption 5watts
Power 200MW(2W/10W option) Battery Life 10hours
Latency 30ms/hop Battery Capacity 5000mAh
FREQUENCY BAND INTERFACE
800MHZ 806Mhz-826Mhz RF 2 x TNC
1.4GHZ 1427.9Mhz-1447.9Mhz HDMI 1 x Standard HDMI Port
2.4GHZ 2401.5Mhz-2481.5Mhz Power on/off 1 x button


Power 1 x DC12V IN
