UAV Megaphone and Drone Speaker for Real-time Speaking broadcast and SD Card audio file display

Hawk-A10 is a megaphone designed for drone, such as multirotor or fixed wing platforms. Based on digital wireless transmission technology. it supports to display audio file in SD card and real-time speaking broadcasting. In this case, it enhances law enforcement, emergency and critical infrastructure operations.
Availability:
  • Hawk-A10

Product Description

Compact and lightweight
The speaker weighs as little as 500 grams to help you meet your payload weight allowanceUAV Speaker


➢Strong Anti-interference Capability
Compared with normal analog signal transmission based megaphone, Hawk-A10 uses advanced digital voice coding technology, which enable the speaker to avoid analog sound interference in the air.


➢Two Working Modes
Hawk-A10 has 2 working modes: play SD card recorded sound and real-time broadcasting. You are able to switch the modes easily on handheld intercom.


➢Not Affect Drone's Geomagnetic Field
Hawk-A10 is using internal magnetic speaker, so it does not affect drone geomagnetic field.


➢1KM and 10KM
Speaker cover range is 1KM while intercom transmission range is 10KM.


➢Accept Sound Customization
You are able to load any sound source to the speaker, no time / size limit, accepted format is MP3 and WAV.


Drone Megaphone Speaker





       Feature

       ➢Lightweight design, only 500grams for speaker.

       ➢All-in one structure and small size, easy for installation and low air resistance.

       ➢Based on digital voice coding technology, can get super clear voice and prevent disturbing              from analog voice sources.

       ➢Two work modes: recorded sound play and real-time broadcasting. Easy switch.

       ➢Internal magnetic speaker, do not affect drone geomagnetic field.

       ➢Anti-squeal design.

       ➢Super clear and high strength sound,great penetrability.





Specification


                                                                    Speaker

Weight

500 grams

Sound Strength

125db (1meters distance)

80db (100meters distance)

Sound Cover Range

1km

Anti-squeal distance

Over 20meters

Voltage

9-28V

Current

100mA

Frequency

410Mhz-470Mhz

Power Connector

XT60(Optional)

4FSK Digital Modulation

Data: 12.5khz

Sound: 7K60FXW

Sound Distortion Percentage

Less Than3%

Signal Receive Sensitivity

-117dBm

Max Signal Receiveing Range

10km

Amplifier Power

100W/60Ω

Handset

Frequency

410Mhz-470Mhz

Channel Number

4Ch

Recorded Sound Number

9

Battery

2200mAh

Charge

Via USB

Current

1500mAh

Power

2watts(33dbm)

Max Transmission Range

10km

Digital Coding Type

AMBE

Digital Protocol

ETSI-TS102, 361-1,-2,-3


Dimension

drone audio broadcasting
